05/2014
6-281
DC SC2020
General
6.6.4.2 FCF/FIF Description
Version 1.1
6.6.4.2 FCF/FIF Description
DIS: 80
DCS: 82/83
DTC: 81
Frame (Signal) List Table sent by Sending Station during F-Code Communication... Frame Name is
printed in protocol
The frame (signal) that can be used is decided according to the capability of the Receiving Station
declared by DIS.
Every frame in the table has to be sent prior to DCS.
When sending, Bit 49 and 50 of DCS and Bit 35, 47, and 50 of DTC must be set to ’1’.
Enter 20 characters for Password in ASCII code (0-9, #, *) and 20 characters for Sub Address in ASCII
code (0-9).
6.6.4.3 Bit 7 Description
64: ECM Frame size (DCS is invalid)
0 -> 256 Octet
1 -> 64 Octet
Refer to ’EFS’ of Bit 28 (6.6.4.15)
Table 1
Frame Name FCF Name/Contents
PWD C1 Password. Enter password in FIF.
Sending permitted only when Bit 50 of DIS is 1.
SEP A1 Selective Polling. Enter the Sub Address in FIF.
Displays the specific document number when used with PSA concurrently.
Sending permitted only when Bit 47 of DIS is 1.
PSA 61 Polling Sub Address. Enter the Sub Address in FIF.
Sending permitted only when Bit 35 of DIS is 1.
SUB C2/C3 Sub Address. Enter the Sub Address of the called party in FIF.
Sending permitted only when Bit 49 of DIS is 1.
SID A2/A3 Sending Station ID. Enter the identification number (Local Station ID) of the
Sending Station in FIF.
Sending permitted only when Bit 50 of DIS is 1.
To Next Page
