05/2014
6-283
DC SC2020
General
6.6.4.6 Bit 15 Description
Version 1.1
6.6.4.6 Bit 15 Description
VR: Vertical Resolution (Slow Scan Linear Density)
0 -> 3.85l/mm 1 -> 3.85l/mm and 7.7l/mm
Also see Bit 44 and 45
• Bit 44: Refer to 6.6.4.22
• Bit 45: Refer to 6.6.4.21
6.6.4.7 Bit 14~11 Description
DSR: Data Signaling Rate (Electrical Transmission Speed), [ ] corresponds to the past machine only
Table 1
14 13 12 11 DIS/DTC DCS
0 0 0 0 V27ter Fall Back 2400 Bit/s: V27ter
0 0 1 0 V27ter 4800 Bit/s: V27ter
0 0 0 1 V29 9600 Bit/s: V29
0 0 1 1 V27ter and V29 7200 Bit/s: V29
0 1 0 0 Not Used Invalid [14400 Bit/s: V33]
0 1 1 0 Preset Invalid [12000 Bit/s: V33]
0 1 0 1 Not Used Preset
0 1 1 1 Invalid [V27ter, V29,
V33]
Preset
1 0 0 0 Not Used 14400 Bit/s: V17
1 0 1 0 Preset 12000 Bit/s: V17
1 0 0 1 Not Used 9600 Bit/s: V17
1 0 1 1 V27ter, V29, [V33] V17 7200 Bit/s: V17
1 1 0 0 Not Used Preset
1 1 1 0 Preset Preset
1 1 0 1 Not Used Preset
1 1 1 1 Preset Preset
