DC SC2020
Wiring Data
7.1 Plug/Jack Location List
Version 1.1
P/J669 12 4 Connector
J690 12 9 Connector (Connect to P630)
P/J700 3 4 CIS Sensor Assy
P/J721 3 2 IIT Scan Motor
P/J722 3 3 IIT Regi. Sensor
P/J723 3 6 Platen Angle Sensor
P/J724 3 5 Platen Close Sensor
P/J725 3 1 APS Sensor 1
P/J751 2 9 DADF PWB
P/J752 2 8 DADF PWB
P/J753 2 7 DADF PWB
P/J754 2 4 DADF PWB
P/J756 2 5 DADF PWB (to Exit Nip Release Solenoid)
P/J758 2 6 DADF PWB
P/J759 2 3 DADF PWB
P/J760 2 2 DADF PWB
P/J761 2 1 DADF PWB
P/J764 1 3 Document Tray Size Sensor 1
P/J765 1 4 Document Tray Size Sensor 2
P/J766 1 6 DADF Tray Set Guide Sensor 3
P/J767 1 5 DADF Tray Set Guide Sensor 2
P/J768 1 2 DADF Tray Set Guide Sensor 1
P/J770 1 1 DADF Document Set Sensor
P/J771 1 7 DADF Invert Sensor
P/J772 1 9 DADF Pre Regi. Sensor
P/J773 1 8 DADF Regi. Sensor
P/J774 2 14 DADF Open Sensor
P/J777 2 13 DADF Feed Motor
P/J780 2 17 DADF Feed Clutch
P/J781 2 12 T/A Clutch
J840 3 7 Connector (Connect to P5)
J950 14 1 Connector (Option)(Connect to P432)
J951 14 3 Connector (Option)(Connect to P1350)
P1350 14 3 Fax PWB (Option)(Connect to J951)
CN1 312UI PWB R
MJ1 14 4 Fax PWB (Option)(LINE)
MJ2 14 5 Fax PWB (Option)(TEL)
F1 2 15 DADF Feeder Cover Interlock Switch
F2 2 16 DADF Feeder Cover Interlock Switch
F10 6 4 Thermostat
Table 1 Plug/Jack Location List
P/J Fig Item Remarkes (where to Connect)
C 52LPH Assy (C)
K 52LPH Assy (K)
M 52LPH Assy (M)
Y 52LPH Assy (Y)
T1 11 14 Terminal (IOT)
T1 2 20 Terminal (DADF)
T2 2 19 Terminal (DADF)
T3 2 11 Terminal (DADF)
T4 2 10 Terminal (DADF)
Table 1 Plug/Jack Location List
P/J Fig Item Remarkes (where to Connect)
