Fuji Xerox DocuCentre SC2020 - Page 764

7.3 BSD
Chain6 Imaging
ABCDEFGHJ
1
2
3
4
5
6
7-26
ESS PWB
PL18.2
6.2 CARRIAGE CONTROL
ELECTRICAL COMPONENTS
IIT SCAN
MOTOR
IIT REGI. SENSOR
FAIL CODE
062-360
062-389
Carriage Position Fail
Carriage Over Run Fail (Scan End Side)
j0bs730602
P721
ESS PWB
PL18.2
J13
1
IIT SCAN MOTOR
ON +24VDC CLOCK A
2
IIT SCAN MOTOR
ON +24VDC CLOCK /A
062-005
IIT SCAN MOTOR
ON +24VDC CLOCK B
3
IIT SCAN MOTOR
ON +24VDC CLOCK /B
BLU
BLU
BLU
BLU
IIT SCAN
MOTOR
PL1.4
J721
4
3
2
1
MOT
(SCAN DIRCTION)
IIT REGI. SENSOR
PL1.3
J722
1
1
3
F34 SLEEP
+5VDC
(1.2 F2)
J19
2
J722
2
DC COM
(1.2 F4)
BLU
BLU
BLU
IIT REGI. SENSOR
BLOCKED (H)+5VDC
062-212
062-360
062-389
062-006
(RETURN DIRCTION)
J19
3
SLEEP
+5VDC
DC COM
DC COM
DC COM
DC COM
+1.2VDC
DC COM
IIT Input
IIT Output
4
SLEEP
+24VDC
(1.3 H4)
F37
