DC SC2020
0.3 Description for Terminology And Symbols
Version 1.1
Introduction
• When the manual is updated, the issue number ’Ver. 1’ will be changed to Ver. 1.1, Ver. 1.2, and so
on.
0.3 Description for Terminology And Symbols
The terms and symbols used throughout this manual are explained here.
• The terms and symbols used at the beginning of a text are defined as follows:
Danger
Indicates an imminently hazardous situation, such as death or serious injury if operators do not
handle the machine correctly by disregarding the statement.
Warning
Indicates a potentially hazardous situation, such as death or serious injury if operators do not
handle the machine correctly by disregarding the statement.
CAUTION
Indicates a potentially hazardous situation, such as injury or property damage if operators do not handle
the machine correctly by disregarding the statement.
Instruction: Used to alert you to a procedure which, if not strictly observed, could result in damage to the
machine or equipment.
NOTE: Used when work procedures and rules are emphasized.
NOTE:Used when other explanations are given.
Purpose
Used to describe the purposes of Adjustment and Troubleshooting.
REP: Indicates the disassembly/assembly procedure for reference.
ADJ: Indicates the adjustment procedure for reference.
PL: Indicates the parts list for reference.
Terminology
Safety Critical Components (SCC)
For the safety control of the Safety Critical Components and the components specified, follow the regula-
tions regarding the Safety Critical Components set by Fuji Xerox Co., Ltd.
As to replacement of any component designated SCC, the complete component unit must be replaced. It
must never be disassembled or no individual internal parts of it must be replaced.
Installation of any part other than the ones designated by Fuji Xerox Co. Ltd. shall be strictly prohibited
because it cannot be guaranteed in quality and safety.
Table 1 Terminology
Terminology Description
Assy Means Assembly.
TEC Value Abbreviation of Typical Electricity Consumption, which means the standard
power consumption. Read as 'tec'.
