HP PageWide Enterprise Color 556

3. Remove two # 10 torx screws (callout 1).
CAUTION: Store the screws in a secure place where they cannot fall down into the printer.
Figure 1-76 Remove two screws
1
4. Lift up the rear edge of the control panel (callout 1), and then slightly slide it toward the rear of the
printer (callout 2) to release the front tabs.
Figure 1-77 Release the control panel over
1
2
70 Chapter 1 Removal and replacement ENWW
