2. Pull the SCB cover straight o the printer to remove it
Figure 1-668 Remove the SCB cover
Step 4: Remove the right cover (outer)
1. Pull out on the top corners of the right cover to release the top edge of the cover.
TIP: Open the cartridge door to make removing the cover easier.
Figure 1-669 Release the right cover (outer)
ENWW Removal and replacement procedures 411
