HP PageWide Enterprise Color 556

3. Remove the cover.
Figure 1-220 Remove the left rear cover
Step 3: Remove the left front cover
NOTE: The gures in this section show the 586 printer. However, the instructions for removing the cover are
valid for 556 printers.
1. Remove one screw (callout 1).
Figure 1-221 Remove one screw
1
ENWW Removal and replacement procedures 167
