Removal and replacement: Formatter cover
●
Introduction
●
Step 1: Remove the formatter cover
●
Step 2: Unpack the replacement assembly
●
Step 3: Install the formatter cover
Introduction
This document provides the procedures to remove and replace the formatter cover.
Before performing service
Turn the printer power o
◦
Disconnect the power cable.
WARNING! To avoid damage to the printer, turn the printer o, wait 30 seconds, and then remove the
power cable before attempting to service the printer.
Use the table below to identify the correct part number for your printer. To order the part, go to
www.hp.com/buy/parts.
Formatter cover part number
G1W39-67915 Formatter cover
IMPORTANT: This cover has a lable on it that contains the printer serial number
and other regulatory information. If a print mechanism (PM) kit is installed, this
cover must be installed on the PM unit.
Required tools
●
No special tools are needed to remove or install this assembly.
After performing service
Turn the printer power on
◦
Connect the power cable.
◦
Use the power switch to turn the power on.
Post service test
No post service test are available for this assembly.
Step 1: Remove the formatter cover
▲
Remove two thumb screws (callout 1), and then slide the cover o of the printer to remove it (callout 2).
NOTE: The thumb screws are not captive and are easily lost.
ENWW Removal and replacement procedures 89
