25. Position the small gray plastic cover in the slot under the control panel, and then push it straight in to
install it.
Figure 1-551 Install the cover
Step 26: Install the control panel (556)
NOTE: This step is for the 556 printer. For the 586 printer, skip this step.
1. Connect one HDMI cable (callout 1) and one connector (callout 2).
Figure 1-552 Connect cables
ENWW Removal and replacement procedures 339
