Step 22: Install the left rear cover
NOTE: The gures in this section show the 586 printer. However, the instructions for removing the cover are
valid for 556 printers.
1. Position the cover on the printer.
Figure 1-387 Install the left rear cover
2. Engage the cover by sliding it down about 10 mm (0.4 in).
Figure 1-388 Engage the cover
ENWW Removal and replacement procedures 255
