HP PageWide Enterprise Color 556

Figure 1-592 Install screwsand connect connectors
1
2
3
Step 9: Install the small outline dual in-line memory module (SODIMM)
CAUTION: ESD-sensitive part.
1. Insert the connector end of the SODIMM into the holder. Make sure that the SODIMM is fully pushed into
the connector.
NOTE: The SODIMM is keyed and can only be inserted into the holder one way.
Figure 1-593 Install the SODIMM
ENWW Removal and replacement procedures 365
