HP PageWide Enterprise Color 556

12. Install the USB port cover.
Figure 1-708 Install the USB port cover
Step 12: Install the document feeder assembly (M586)
1. Pass the at cable and wire harness on the replacement document feeder through the hole in the
scanner chassis (callout 1), and then align the hinges (callout 2) with the slots (callout 3) in the chassis.
Figure 1-709 Align the hinges
1
3
2
432 Chapter 1 Removal and replacement ENWW
