HP PageWide Enterprise Color 556

Turn the printer power on
◦
Connect the power cable.
◦
Use the power switch to turn the power on.
Post service test
Print a conguration page to make sure that the printer is functioning correctly.
Step 1: Remove the formatter cover
▲
Remove two thumb screws (callout 1), and then slide the cover o of the printer to remove it (callout 2).
NOTE: The thumb screws are not captive and are easily lost.
Figure 1-62 Remove the formatter cover
2
1
Step 2: Remove the embedded MultiMedia Card (eMMC)
CAUTION:
ESD-sensitive part.
NOTE: M506 (all) and M527dn printers only.
▲
Locate the eMMC component on the formatter, and then pull it straight o of the formatter to remove it.
ENWW Removal and replacement procedures 55
