2. Unpack the replacement part from the packaging.
CAUTION: If the replacement part is a roller or pad, avoid touching the spongy part of it. Skin oils on
the roller or pad can cause paper pickup and/or print-quality problems. HP recommends using
disposable gloves when handling rollers or pads or washing your hands or before touching rollers or
pads.
IMPORTANT: Make sure that all of the shipping materials (for example shipping tape) are removed
from the replacement part prior to installation.
Step 3: Install the internal USB port module
CAUTION:
ESD-sensitive part.
1. Position the notches on the internal USB ports PCA over the clips on the PCA holder and press down to
attach the PCA to the holder. Make sure that the clips snap into place.
Figure 1-997 Install the PCA in the holder
608 Chapter 1 Removal and replacement ENWW
