Removal and replacement: Left-front top cover cap (556)
Introduction
This document provides the procedures to remove and replace the left-front top cover cap (M556).
Before performing service
Turn the printer power o
◦
Disconnect the power cable.
WARNING! To avoid damage to the printer, turn the printer o, wait 30 seconds, and then remove the
power cable before attempting to service the printer.
Use the table below to identify the correct part number for your printer. To order the part, go to
www.hp.com/buy/parts.
Left-front top cover cap (M556) part number
G1W46-67909 Left-front top cover cap (M556)
Required tools
●
No special tools are needed to remove or install this assembly.
After performing service
Turn the printer power on
◦
Connect the power cable.
◦
Use the power switch to turn the power on.
Post service test
No post service test are available for this assembly.
Step 1: Remove the left-front top cover cap (556)
▲
Open the left door, and then carefully pull the cover o of the printer.
TIP: It might be easier remove the cover o by using a small at-blade screwdriver.
ENWW Removal and replacement procedures 99

HP PageWide Enterprise Color 556 Specifications

General

Print resolution (best)	1200 x 1200 DPI
Duplex printing	Yes
Ethernet LAN	Yes
Scanner Type	Flatbed, ADF
Fax Modem Speed	33.6 Kbps
Processor frequency	1.2 GHz
Mobile printing technologies	HP ePrint, Apple AirPrint, Mopria-certified, Google Cloud Print 2.0
Functions	Print
Maximum Scan Size	216 x 356 mm
Connectivity	USB, Ethernet, Wi-Fi
Operating System Compatibility	Windows, macOS, Linux
Print speed (black, normal quality, A4/US Letter)	Up to 75 ppm
Print Speed (Color)	Up to 75 ppm
