HP PageWide Enterprise Color 556

4. Release the bosses along the right and left side of the cover, and then lift it straight up to remove it.
Figure 1-230 Remove the rear cover
1
2
1
2
Step 7: Remove the top cover (586)
1. Remove eight screws (callout 1).
Figure 1-231 Remove eight screws
1
172 Chapter 1 Removal and replacement ENWW
