2. Unpack the replacement part from the packaging.
CAUTION: If the replacement part is a roller or pad, avoid touching the spongy part of it. Skin oils on
the roller or pad can cause paper pickup and/or print-quality problems. HP recommends using
disposable gloves when handling rollers or pads or washing your hands or before touching rollers or
pads.
IMPORTANT: Make sure that all of the shipping materials (for example shipping tape) are removed
from the replacement part prior to installation.
Step 7: Install the SCB (M586)
1. Position the SCB (callout 1) in the slot (callout 2) in the printer.
NOTE: Make sure that all of the cables are outside of the slot before installing the SCB.
Figure 1-637 Install the SCB
ENWW Removal and replacement procedures 393
