3. Install one screw (callout 1).
Figure 1-262 Install one screw
Step 14: Install the left rear cover
NOTE: The gures in this section show the 586 printer. However, the instructions for removing the cover are
valid for 556 printers.
1. Position the cover on the printer.
Figure 1-263 Install the left rear cover
ENWW Removal and replacement procedures 189
