Printer back view (586 models)
1 Document-feeder cover (access for clearing jams or cleaning rollers)
2 Easy-access USB port
Insert a USB ash drive for printing or scanning without a computer or to update the printer rmware.
NOTE: An administrator must enable this port before use.
3 Left door (access to the ink-collection unit and for clearing jams)
4 Tray 1
5 Power connection
6 Formatter cover
7 Serial number and product number label
8 Formatter (contains the interface ports)
9 Slot for a cable-type security lock (on the rear cover of the printer)
