HP PageWide Enterprise Color 556

5. Remove the cover.
NOTE: Pass the control-panel cable and wire harness through the opening in the cover as it is
removed.
Figure 1-469 Remove the top cover (556)
6. Optional step: If a replacement top cover is being installed, remove the output bin ap by exing the
center of the ap to release the right- and left-side hinge pins from the holes in the cover.
Figure 1-470 Remove the output bin ap
Step 11: Remove the top cover (586)
NOTE: This step is for the 586 printer. For the 556 printer, skip this step and go to Step 12: Removal the
front cover on page 303.
1. Remove eight screws (callout 1).
298 Chapter 1 Removal and replacement ENWW
