3. Close the roller cover.
Figure 1-975 Close the roller cover
4. Push down to snap the cover into place.
NOTE: When the cover is correctly installed, an audible click is heard when it snaps into place.
Figure 1-976 Push down on the roller cover
Step 5: Install the document feeder pickup and feed roller assembly
NOTE: This guide shows the HP LaserJet Enterprise MFP M527. However, the instructions are also valid for
the HP PageWide Enterprise Color MFP 586.
588 Chapter 1 Removal and replacement ENWW
