5. Connect one HMDI cable (callout 1), and then connect two connectors (callout 2).
NOTE:
Figure 1-773 Connect connectors
2
1
Step 11: Install the rear cover
1. Before proceeding, take note of the tabs and bosses on the rear cover.
Figure 1-774 Find the tabs and bosses on the rear cover
