HP PageWide Enterprise Color 556 User Manual

Removal and replacement: Output bin
●
Introduction
●
Step 1: Remove the right cover (outer)
●
Step 2: Remove the output bin
●
Step 2: Unpack the replacement assembly
●
Step 4: Install the output bin
●
Step 5: Install the right cover (outer)
Introduction
This document provides the procedures to remove and replace the output bin.
Before performing service
Turn the printer power o
◦
Disconnect the power cable.
WARNING! To avoid damage to the printer, turn the printer o, wait 30 seconds, and then remove the
power cable before attempting to service the printer.
Use the table below to identify the correct part number for your printer. To order the part, go to
www.hp.com/buy/parts.
Output bin kit part number
G1W39-67944 Output bin with instruction guide
Required tools
●
No special tools are needed to remove or install these assemblies.
After performing service
Turn the printer power on
◦
Connect the power cable.
◦
Use the power switch to turn the power on.
Post service test
Send a color print job to the printer.
Step 1: Remove the right cover (outer)
1. Pull out on the top corners of the right cover to release the top edge of the cover.
TIP: Open the cartridge door to make removing the cover easier.
ENWW Removal and replacement procedures 13

HP PageWide Enterprise Color 556 Specifications

General

Print resolution (best)	1200 x 1200 DPI
Duplex printing	Yes
Ethernet LAN	Yes
Scanner Type	Flatbed, ADF
Fax Modem Speed	33.6 Kbps
Processor frequency	1.2 GHz
Mobile printing technologies	HP ePrint, Apple AirPrint, Mopria-certified, Google Cloud Print 2.0
Functions	Print
Maximum Scan Size	216 x 356 mm
Connectivity	USB, Ethernet, Wi-Fi
Operating System Compatibility	Windows, macOS, Linux
Print speed (black, normal quality, A4/US Letter)	Up to 75 ppm
Print Speed (Color)	Up to 75 ppm
