3. Rotate the right edge of the formatter away from the printer (callout 1) to release the tabs identied in
the previous step, and then slide the formatter to the right (callout 2) to remove it.
Figure 1-588 Remove the formatter
Step 7: Unpack the replacement assembly
1. Dispose of the defective part.
NOTE: HP recommends responsible disposal of the defective part.
http://www8.hp.com/us/en/hp-information/environment/product-recycling.html
362 Chapter 1 Removal and replacement ENWW
