2. Unpack the replacement part from the packaging.
CAUTION: If the replacement part is a roller or pad, avoid touching the spongy part of it. Skin oils on
the roller or pad can cause paper pickup and/or print-quality problems. HP recommends using
disposable gloves when handling rollers or pads or washing your hands or before touching rollers or
pads.
IMPORTANT: Make sure that all of the shipping materials (for example shipping tape) are removed
from the replacement part prior to installation.
Step 4: Install the pickup and separation roller assemblies
1. Locate the tabs and pins on the replacement roller.
CAUTION: Avoid touching the spongy part of roller. Skin oils on the roller can cause paper pickup
and/or print-quality problems. HP recommends using disposable gloves when handling roller or washing
your hands before touching rollers.
NOTE: There is one pin and one tab one each side of the roller.
Figure 1-569 Remove the roller
350 Chapter 1 Removal and replacement ENWW
