2. Install the tabs on either side of the roller into the notches on the holder.
TIP: The holder might need to be repositioned if it rotated while removing the roller.
Figure 1-570 Install the tabs
3. Rotate the roller up until the pins snap into the slots on the holder.
Reinstallation tip: An audible click can be heard when the pins snap into the slots on the roller holder.
Make sure that the roller is securely fastened in the holder.
Figure 1-571 Install the pins
ENWW Removal and replacement procedures 351
