After performing service
Turn the printer power on
◦
Connect the power cable.
◦
Use the power switch to turn the power on.
Post service test
No post service test are available for this assembly.
Step 1: Remove the integrated scanner assembly (ISA; 586)
NOTE: The ISA includes the document feeder, sub-scanner assembly (SSA), and the scanner control board
(SCB)
586 printers only.
1. If the control panel is in the down position, tilt it up to the fully raised position, and then open the
document feeder.
Figure 1-195 Tilt the control panel up
154 Chapter 1 Removal and replacement ENWW
