HP PageWide Enterprise Color 556

Figure 1-128 Remove the formatter cover
2
1
Step 3: Remove the rear cover
1. Remove eight screws (callout 1).
NOTE: Two of these screws (callout 2) are a dierent type (machine screws) than the others.
Figure 1-129 Remove eight screws
1
2
116 Chapter 1 Removal and replacement ENWW
