Figure 1-258 Position the right cover (outer) on the printer
2. Push in along the top edge of the right cover (outer) to install it.
Figure 1-259 Install the right cover (outer)
Step 13: Install the left front cover
NOTE: The gures in this section show the 586 printer. However, the instructions for removing the cover are
valid for 556 printers.
1. Position the cover on the printer.
ENWW Removal and replacement procedures 187
