Removal and replacement: Left front cover
Introduction
This document provides the procedures to remove and replace the left front cover.
Before performing service
Turn the printer power o
◦
Disconnect the power cable.
WARNING! To avoid damage to the printer, turn the printer o, wait 30 seconds, and then remove the
power cable before attempting to service the printer.
Use the table below to identify the correct part number for your printer. To order the part, go to
www.hp.com/buy/parts.
Left front cover part number
G1W39-67916 Left-front cover
Required tools
●
#10 Torx driver with a 152 mm (6 in) shaft and magnetized tip.
After performing service
Turn the printer power on
◦
Connect the power cable.
◦
Use the power switch to turn the power on.
Post service test
No post service test are available for this assembly.
Step 1: Remove the left-front top cover cap (556)
NOTE: This step is for the 556 printer only. For the 586 printer, skip this step and go to Step 2: Remove the
left front cover on page 109.
▲
Open the left door, and then carefully pull the cover o of the printer.
TIP: It might be easier remove the cover o by using a small at-blade screwdriver.
108 Chapter 1 Removal and replacement ENWW
