HP PageWide Enterprise Color 556

Figure 1-861 Remove the formatter cover (PM)
Step 4: Remove the rear cover (PM)
This cover might have come o when the blue shipping tape was removed earlier after unpacking the PM. If
so, skip this step.
1. Remove six screws (callout 1).
Figure 1-862 Remove six screws
1
ENWW Removal and replacement procedures 523
