HP PageWide Enterprise Color 556

5. At the rear of the printer, engage two tabs (callout 1/2).
NOTE: To locate the tabs, see step 2.
Figure 1-509 Engage two tabs
2
1
6. On the left side of the printer, install two screws (callout 1).
Figure 1-510 Install two screws
1
Step 18: Install the rear cover
1. Before proceeding, take note of the tabs and bosses on the rear cover.
318 Chapter 1 Removal and replacement ENWW
