2. Slide the output bin toward the printer to install it.
NOTE: Make sure that the output bin is completely installed against the printer with no gaps in
between.
Figure 1-6 Install the output bin
Step 5: Install the right cover (outer)
1. Position the bottom edge of the cover on the printer.
Figure 1-7 Position the right cover (outer) on the printer
ENWW Removal and replacement procedures 17
