HP PageWide Enterprise Color 556

5. Remove the cover.
NOTE: Pass the control-panel cable and wire harness through the opening in the cover as it is
removed.
Figure 1-166 Remove the top cover (556)
6. Optional step: If a replacement top cover is being installed, remove the output bin ap by exing the
center of the ap to release the right- and left-side hinge pins from the holes in the cover.
Figure 1-167 Remove the output bin ap
Step 10: Install the top cover (556)
1. Optional step: If a replacement top cover is being installed, install the output bin ap by exing the
center of the ap and installing the right- and left-side hinge pins in the holes in the cover.
