Removal and replacement: Right cover (outer)
●
Introduction
●
Step 1: Remove the right cover (outer)
●
Step 2: Unpack the replacement assembly
●
Step 3: Install the right cover (outer)
Introduction
This document provides the procedures to remove and replace the right cover (outer).
Before performing service
Turn the printer power o
◦
Disconnect the power cable.
WARNING! To avoid damage to the printer, turn the printer o, wait 30 seconds, and then remove the
power cable before attempting to service the printer.
Use the table below to identify the correct part number for your printer. To order the part, go to
www.hp.com/buy/parts.
Formatter cover part number
G1W39-67922 Right cover (outer)
NOTE: In the parts chapter, the right cover (outer) is named: case, right trim.
Required tools
●
No special tools are needed to remove or install this assembly.
After performing service
Turn the printer power on
◦
Connect the power cable.
◦
Use the power switch to turn the power on.
Post service test
No post service test are available for this assembly.
Step 1: Remove the right cover (outer)
1. Pull out on the top corners of the right cover to release the top edge of the cover.
TIP: Open the cartridge door to make removing the cover easier.
92 Chapter 1 Removal and replacement ENWW
