2. Unpack the replacement part from the packaging.
CAUTION: If the replacement part is a roller or pad, avoid touching the spongy part of it. Skin oils on
the roller or pad can cause paper pickup and/or print-quality problems. HP recommends using
disposable gloves when handling rollers or pads or washing your hands or before touching rollers or
pads.
IMPORTANT: Make sure that all of the shipping materials (for example shipping tape) are removed
from the replacement part prior to installation.
Step 1: Install the left door
1. Position the shaft on the left door into the opening in the printer (callout 1), and then rotate the door
toward the printer (callout 2).
Figure 1-90 Install the left door
ENWW Removal and replacement procedures 81
