HP PageWide Enterprise Color 556

2. Position the bracket on the printer.
NOTE: The bracket placement might need to be adjusted, so do not install the mounting screws until
after the power supply is installed.
Figure 1-833 Install the bracket
Step 17: Install the power supply (PM)
1. Install the power supply.
Figure 1-834 Install the power supply.
1
2
ENWW Removal and replacement procedures 503
