Install accessory: Internal USB ports
THIS SECTION IS FOR PLACEMENT ONLY (FPO). FULL TEXT AND GRAPHICS ARE IN DEVELOPMENT AND IN
REVIEW AS CRU/FRU INSTALL GUIDE. THAT FINAL CONTENT WILL BE LEVERED HERE AT VERIFICATION.
●
Introduction
●
Step 1: Remove the formatter cover
●
Step 2: Unpack the replacement assembly
●
Step 3: Install the internal USB port module
●
Step 4: Install the formatter cover
Introduction
This document provides the procedure to install the internal USB ports accessory.
Before performing service
Turn the printer power o
◦
Disconnect the power cable.
WARNING! To avoid damage to the printer, turn the printer o, wait 30 seconds, and then remove the
power cord before attempting to service the printer.
CAUTION: This part contains components that are electrostatic discharge (ESD) sensitive. To reduce
the possibility of ESD damage, always touch the sheet-metal chassis to ground yourself before touching an
ESD sensitive part.
Use the table below to identify the correct part number for your printer. To order the part, go to
www.hp.com/buy/parts.
Internal USB ports accessory part number
B5L28A (accessory)
B5L28-67902 (service kit)
Internal USB ports (accessory) with instruction guide
Internal USB ports (service) with instruction guide
Required tools
No special tools are required to install this part.
After performing service
Turn the printer power on
◦
Connect the power cable.
◦
Use the power switch to turn the power on.
Post service test
Make sure that the printer initializes to a Ready state.
606 Chapter 1 Removal and replacement ENWW
