9. Position the small gray plastic cover in the slot under the control panel, and then push it straight in to
install it.
Figure 1-738 Install the cover
Step 19: Install the white backing
▲
Follow the instruction guides provided in the kit to install the document feeder retention clips and white
backing.
Figure 1-739 Install the retention clips and white backing
ENWW Removal and replacement procedures 447
