9. Use a nger to hold the roller in place (callout 1), and then rotate the roller and holder up (callout 2) to
expose the roller.
Figure 1-567 Release the roller
10. Remove the roller.
Figure 1-568 Remove the roller
Step 3: Unpack the replacement assembly
1. Dispose of the defective part.
NOTE: HP recommends responsible disposal of the defective part.
http://www8.hp.com/us/en/hp-information/environment/product-recycling.html
ENWW Removal and replacement procedures 349
