Figure 1-110 Remove left-front top cover cap (556)
Step 2: Remove the left rear cover
NOTE: The gures in this section show the 586 printer. However, the instructions for removing the cover are
valid for 556 printers.
1. Remove two screws (callout 1).
Figure 1-111 Remove two screws
ENWW Removal and replacement procedures 103
