Removal and replacement: Control panel keyboard (586z)
●
Introduction
●
Step 1: Remove the control panel keyboard
●
Step 2: Unpack the replacement assembly
●
Step 3: Install the control panel keyboard
Introduction
This document provides the procedures to remove and replace the control panel keyboard (586).
Before performing service
Turn the printer power o
◦
Disconnect the power cable.
WARNING! To avoid damage to the printer, turn the printer o, wait 30 seconds, and then remove the
power cable before attempting to service the printer.
Use the table below to identify the correct part number for your printer. To order the part, go to
www.hp.com/buy/parts.
Control panel keyboard kit part number
G1W41-67938
G1W41-67959
Control panel keyboard US (586z) with instruction guide
Control panel keyboard UK (586z) with instruction guide
Required tools
●
Optional: Small at-blade screwdriver.
After performing service
Turn the printer power on
◦
Connect the power cable.
◦
Use the power switch to turn the power on.
Post service test
Verify that the control panel keyboard is correctly functioning. If the keyboard is unresponsive after turning
the printer on, check the at cable. Reinstall the cable if necessary.
Step 1: Remove the control panel keyboard
1. Tilt the control panel to the fully raised position and open the document feeder.
ENWW Removal and replacement procedures 45
