HP PageWide Enterprise Color 556 - Step 8: Remove the rear cover (DU)

Figure 1-797 Release the right cover (outer)
2. Slide the cover up and away from the printer to remove it.
Figure 1-798 Remove the right cover (outer)
Step 8: Remove the rear cover (DU)
1. Remove eight screws (callout 1).
NOTE: Two of these screws (callout 2) are a dierent type (machine screws) than the others.
ENWW Removal and replacement procedures 485
