Removal and replacement: Sub-scanner assembly (SSA) (586)
●
Introduction
●
Step 1: Remove the white backing
●
Step 2: Removal the control panel (586)
●
Step 3: Remove the scanner control board (SCB) cover
●
Step 4: Remove the right cover (outer)
●
Step 5: Remove the formatter cover
●
Step 6: Remove the rear cover
●
Step 7: Remove the scanner control board (SCB) (M586)
●
Step 8: Remove the document feeder assembly (M586)
●
Step 9: Remove the sub-scanner assembly (SSA)
●
Step 10: Unpack the replacement assembly
●
Step 11: Install the sub-scanner assembly (SSA)
●
Step 12: Install the document feeder assembly (M586)
●
Step 13: Install the SCB (M586)
●
Step 14: Install the rear cover
●
Step 15: Install the formatter cover
●
Step 16: Install the right cover (outer)
●
Step 17: Install the SCB cover
●
Step 18: Install the control panel (556)
●
Step 19: Install the white backing
Introduction
This document provides the procedures to remove and replace the sub-scanner assembly (SSA) (586).
Before performing service
Turn the printer power o
◦
Disconnect the power cable.
WARNING! To avoid damage to the printer, turn the printer o, wait 30 seconds, and then remove the
power cable before attempting to service the printer.
Use the table below to identify the correct part number for your printer. To order the part, go to
www.hp.com/buy/parts.
