5. Install eight screws (callout 1).

NOTE: Two of these screws (callout 2) are a dierent type (machine screws) than the others. Make sure

that they are installed in the correct position.

Figure 1-178 Install eight screws

Step 12: Install the formatter cover

▲

Slide the cover onto the printer (callout 1) to install it, and then install two thumb screws (callout 2).

Figure 1-179 Install the formatter cover

Step 13: Install the right cover (outer)

1. Position the bottom edge of the cover on the printer.

144 Chapter 1 Removal and replacement ENWW
