HP PageWide Enterprise Color 556

3. Starting at the bottom of the cover and working upward, push in along the edges of the cover to engage
the bosses along the right and left side of the cover (callout 1).
NOTE: Make sure that the bottom edge of the cover (callout 2) remains engaged.
Figure 1-176 Engage the sides of the cover
1
2
1
2
4. Starting at the right upper corner of the cover and working toward the left, push in along the top edge of
the cover to engage the bosses along the top of the cover.
Figure 1-177 Release the top edge of the cover
ENWW Removal and replacement procedures 143
