5. Connect one HDMI cable (callout 1), and then connect two connectors (callout 2).
Figure 1-951 Connect connectors
Step 19: Install the rear cover (PM)
1. Before proceeding, take note of the tabs and bosses on the rear cover.
Figure 1-952 Find the tabs and bosses on the rear cover
568 Chapter 1 Removal and replacement ENWW
