2. Unpack the replacement part from the packaging.
CAUTION: If the replacement part is a roller or pad, avoid touching the spongy part of it. Skin oils on
the roller or pad can cause paper pickup and/or print-quality problems. HP recommends using
disposable gloves when handling rollers or pads or washing your hands or before touching rollers or
pads.
IMPORTANT: Make sure that all of the shipping materials (for example shipping tape) are removed
from the replacement part prior to installation.
Step 9: Install the top cover (586)
1. Optional step: If a replacement top cover is being installed, install the output bin ap by exing the
center of the ap and installing the right- and left-side hinge pins in the holes in the cover.
Figure 1-241 Install the output bin ap
178 Chapter 1 Removal and replacement ENWW
