Figure 1-118 Remove left-front top cover cap (556)
Step 2: Remove the left front cover
NOTE: The gures in this section show the 586 printer. However, the instructions for removing the cover are
valid for 556 printers.
1. Remove one screw (callout 1).
Figure 1-119 Remove one screw
ENWW Removal and replacement procedures 109
